KSQ type bridge crane design,production and inspection carry out the last issued relevant national standard, equivalently adopts some foreign criteria including FEM, DIN and IEC. This model overhead crane is designed under GB regulation, passed ISO, CE certification. The crane lifting and travelling speeds are steady and accurate.

Compared with the general QD type bridge crane, its weight is reduced by about 15~30%, the maximum wheel pressure is reduced by about 10~35%, which can the requirements of crane for factory building structure and reduce production cost. As the core component of driving mechanism, reducer gear pair with hard tooth surface and high precision gear set, forged wheel and variable-frequency speed regulating system, which makes this type of crane become renewal product of traditional general bridge crane.

Design Standard

1. Overhead crane and gantry crane manufacturing and tolerances of rail installation GB/T10183-2005

2. Crane test specification and procedures GB/T5905-1986

3. Crane electric control equipment JB/T4315-1997

4. Important application wire rope GB8918-2006

5. Carbon structure steel GB/T700-2006

6. Low alloy high strength structure steel GB/T1591-2008

7. Welding joint radiographic inspection standard JB928-1994

8. Steel welding joint manual ultrasonic flaw detection way GB11345-1989

Double girder overhead crane is composed with double girder frame, crane traveling end truck, and the top running trolley with lifting and travelling device. The motors, reducers and brakes in this model crane lifting and traveling mechanism are separate parts, which makes the crane higher working duty from A3~A8 (ISO) and faster lifting and traveling speeds.

The cranes standard speeds are adjustable, which allow the crane adjust its speed under 10 grades speeds. It could move very slow which makes it possible to do very accurate works.

Safety Feature:

1. Overload protection in the event of overload, the hoist unit switches off and only the lowering motion is possible

2. Long and cross travel limited by means of preliminary and final limit switches or infrared anti-collision device

3. Anti-falling protection for the Three-in-One electric motor of trolley and crane prevents from accidental falling

4. All movements can be switched off by actuating the emergency-off switch at the control station via a main contact

5. High quality long time bearing polyurethane materials buffer fixed at the end of trolley travelling and crane travelling to prevent over traveling

6. Safety hook latch used for avoiding the lifted material out off from the hook

7. Audible and visual alarm device to inform the person stay near by the travelling crane

8. Rain Cover for lifting mechanism of outdoor cranes, electric cabinet and driving mechanism

9. Protective earth conductor is fitted as standard

10. Voltage lower protection system

11. Current overload protection system and more (contact with us more details)

Please inform us the following data for the purpose of servicing you better!

Lifting capacity.

Span (rail center to rail center)

Lifting height (Lowest point to ground)

Power supply (380V, 50Hz, AC, 3-Phase, is that ok?)

Working condition: Which materials to lift? Temperature?

New type single girder bridge crane is design widely used for factories, workshop or warehouse heavy loads transferring in mechanical, Metallurgy, petroleum, petrochemical, ports, railways, civil aviation, electricity, food, paper, building materials, electronics. Especially for loads precise position or precision assembly of large spare parts.

Installation Service

Henan Mine Crane Co.,LTD crane could supply not only overhead crane but also the overhead crane solutions.

Firstly, we will supply overhead bridge crane design, overhead crane manual, overhead crane drawing, overhead crane wiring diagram, overhead crane electrical diagram and overhead crane safety video before or after delivery, our technician will do supervision the installation according to the document, of course, the customer can do installation by themselves according to their requirement.

After installation, our technician will indicate to do the load test according to the overhead crane load test procedure, then overhead crane operator training and overhead crane maintenance training, all the procedure will be made according to the overhead crane training videos and overhead crane training PowerPoint.

Product Application Scenarios for New Types Heavy Duty Double Girder Overhead Crane

The New Types Heavy Duty Double Girder Overhead Crane is engineered for a multitude of demanding applications across various industries, providing an effective solution for transporting

heavy loads with precision and efficiency. Below are key application scenarios where this state-of-the-art crane shines:

Manufacturing Facilities: In manufacturing environments, this overhead crane excels at moving substantial components and materials between production lines. Its robust design ensures

reliability during heavy load transfers, facilitating a seamless workflow and enhancing overall productivity.

Workshops and Assembly Areas: The crane's capabilities are particularly beneficial in workshops where precision is key. It allows for the accurate positioning of large spare parts, making it

an ideal choice for assembly tasks that demand meticulousness and care.

Metallurgy: In the metallurgy sector, where materials are often extremely heavy and require careful handling, our crane performs with excellence. It is designed to safely lift and transport

molten metals and heavy casting parts, adhering to the stringent safety protocols of the industry.

Petroleum and Petrochemical Industries: The crane is adept at moving heavy loads in oil refineries and petrochemical plants, essential for transporting bulky equipment and materials, which

are crucial to maintaining operational efficiency and safety.

Ports and Shipping: Within port facilities, the overhead crane plays a vital role in loading and unloading containers and heavy cargo from ships. Its ability to handle large weights with

precision reduces turnaround times and increases cargo handling efficiency.

Railways and Civil Aviation: In railway and aviation sectors, the crane assists in the assembly and maintenance of trains and aircraft. It is capable of lifting heavy components, such as engines

and fuselage sections, ensuring that safety and precision are upheld during repairs and maintenance.

Electrical and Power Generation: Within energy plants, this crane is invaluable for transferring heavy equipment, such as transformers and generators, throughout different stages of

installation and maintenance, thereby ensuring operational efficiency.

Food and Paper Industries: In food processing and paper production plants, the overhead crane’s design aids in the effective handling of bulk materials as well as the precise placement

of machinery and components, contributing to a streamlined production process.

Building Materials and Construction: In the construction sector, it is essential for transporting heavy building materials and equipment, maximizing productivity on job sites while ensuring

safety standards are met.

Electronics Manufacturing: The crane is also utilized in electronics manufacturing where sensitive components need to be handled with care; it enables the efficient movement of heavy

machinery and materials while maintaining the integrity of delicate parts.
